7.3.11 General fault messages
Table34: Error codes, causes and response
Error code on the
display
Cause Status Action
E01 Excessive temperature Alarm Pump stops.
E02 Overcurrent Alarm Pump stops.
E03 Internal fault Alarm Pump stops.
E04 Blocked rotor Alarm Pump stops.
E05 Temperature limit reached Warning Speed is reduced.
E06 Voltage error Alarm Pump stops.
E07 Test alarm
6)
Alarm -
E08 Motor fault Alarm Pump stops.
E09 High fluid temperature Warning -
E11 Broken wire of temperature sensor (NTC)
in the motor
Warning Speed is reduced.
E12 Firmware update required Alarm Pump stops.
E13 No pump model stored Alarm Pump stops.
E15 Minimum flow Warning -
E16 Maximum flow Warning -
I10 Broken wire at analog input Information The pump behaviour can be set
via the
KSB ServiceTool.
I14 For dual pumps both pumps are
programmed as "left pump".
Information Pumps keep running.
7.4 Resetting the factory setting
To reset the factory setting of the pump press the control button for more than
30seconds.
This comprises the following settings:
Operating mode Proportional-pressure control
Functions The Dual, Modbus, 0-10V functions are disabled.
Setpoints 50%
Modbus parameter baud rate 19.200 Baud
Modbus parameter slave ID 17
Modbus parameter parity Even
6) Further information in the KSB ServiceTool supplementary operating manual
