9. Dispose of joint rings 400.01/.02.
7.4.7.2 Dismantling the economy bearing assembly
✓ The notes and steps stated in (⇨ Section 7.4.1 Page 48) to (⇨ Section 7.4.7 Page
51) have been observed/carried out.
1. Carefully press shaft 210 with deep groove ball bearing 321.01/.02 out of the
bearing bracket.
2. Heat up the deep groove ball bearing to 80°C and pull it off shaft 210.
On grease-lubricated models, pull deep groove ball bearing 321.01/.02 off the
shaft in cold condition.
3. Dispose of joint rings 400.01/.02.
7.5 Reassembling the pump set
7.5.1 General information/Safety regulations
WARNING
Improper lifting/moving of heavy assemblies or components
Personal injury and damage to property!
▷ Use suitable transport devices, lifting equipment and lifting tackle to move
heavy assemblies or components.
CAUTION
Improper reassembly
Damage to the pump!
▷ Reassemble the pump (set) in accordance with the general rules of sound
engineering practice.
▷ Use original spare parts only.
Always reassemble the pump in accordance with the corresponding general assembly
drawing.
▪ Gaskets
– Always use new gaskets, making sure that they have the same thickness as
the old ones.
– Always fit gaskets of asbestos-free materials or graphite without using
lubricants (e.g. copper grease, graphite paste).
▪ O-rings
– Never use O-rings that have been made by cutting an O-ring cord to size and
gluing the ends together.
▪ Packing rings
– Always use pre-compressed packing rings
CAUTION
Contact of O-ring with graphite or similar material
Fluid could escape!
▷ Do not coat O-ring with graphite or similar material.
▷ Use animal fats or lubricants based on silicone or PTFE.
▪ Assembly adhesives
– For gaskets, avoid the use of assembly adhesives, if possible.
– If assembly adhesives are required, use a commercially available contact
adhesive (e.g. "Pattex").
– Only apply adhesive at selected points and in thin layers.
Sequence
Sealing elements
7 Servicing/Maintenance
52 of 74
