5.5 Enclosure/insulation
DANGER
Risk of potentially explosive atmosphere due to insufficient venting
Explosion hazard!
Make sure the space between the casing cover/discharge cover and the bearing
cover is sufficiently vented.
Never close or cover the perforation of the bearing bracket guards (e.g. by
insulation).
WARNING
The volute casing and casing/discharge cover take on the same temperature as the
fluid handled
Risk of burns!
Insulate the volute casing.
Fit protective equipment.
CAUTION
Heat build-up in the bearing bracket
Damage to the bearing!
Never insulate the casing cover and the bearing bracket.
5.6 Checking the coupling alignment
DANGER
Inadmissible temperatures at the coupling or bearings due to misalignment of the
coupling
Explosion hazard!
Risk of burns!
Make sure that the coupling is correctly aligned at all times.
CAUTION
Misalignment of pump and motor shafts
Damage to pump, motor and coupling!
Always check the coupling after the pump has been installed and connected to
the piping.
Also check the coupling of pump sets supplied with pump and motor mounted
on the same baseplate.
5 Installation at Site
MegaCPK
27 of 74
