KSB MegaCPK User Manual

7.7.3 Interchangeability of pump components
Components featuring the same number in a column are interchangeable.
Table 28: Interchangeability of pump components
Size Bearing bracket
Description
Casing cover Support foot Shaft, medium-duty
Shaft, economy Rolling element bearing Radial ball bearing Radial ball bearing
Radial roller bearing Bearing bracket
Casing wear ring
16)
Casing wear ring
16)
Casing wear ring
17)
Impeller wear ring
17)
Casing wear ring
17)
Impeller wear ring
17)
Thrower Thrower Shaft protecting sleeve
18)
Impeller nut
Mechanical seal Seal cover
Gland follower
Stuffing box ring Lantern ring
Gland packing
Part No.
161 183 210 210 320.01 321.01 321.02 322.01 330 502.01 502.02 502.01 503.01 502.02 503.02 507.01 507.02 524.01 922 433 471.07 452.01 454.01 458.01 461.01
040-025-160 CS40 1 1 1 1 1 1 1 1 1 1 - 1 1 - - 1 1 1 1 1 1 1 1 1 1
040-025-200 CS40 2 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
050-032-125 CS40 1 3 1 1 1 1 1 1 1 3 - 3 3 - - 1 1 1 1 1 1 1 1 1 1
050-032-125.1 CS40 1 3 1 1 1 1 1 1 1 2 - 2 2 - - 1 1 1 1 1 1 1 1 1 1
050-032-160 CS40 1 1 1 1 1 1 1 1 1 3 1 3 3 1 1 1 1 1 1 1 1 1 1 1 1
050-032-160.1 CS40 1 1 1 1 1 1 1 1 1 2 1 2 2 - - 1 1 1 1 1 1 1 1 1 1
050-032-200 CS40 2 2 1 1 1 1 1 1 1 3 1 4 4 1 1 1 1 1 1 1 1 1 1 1 1
050-032-200.1 CS40 2 2 1 1 1 1 1 1 1 2 1 2 2 1 1 1 1 1 1 1 1 1 1 1 1
065-040-125 CS40 1 3 1 1 1 1 1 1 1 5 - 4 4 - - 1 1 1 1 1 1 1 1 1 1
065-040-160 CS40 1 1 1 1 1 1 1 1 1 5 1 4 4 1 1 1 1 1 1 1 1 1 1 1 1
065-040-160.1 CS40 1 1 1 1 1 1 1 1 1 4 1 5 5 1 1 1 1 1 1 1 1 1 1 1 1
065-040-200 CS40 2 2 1 1 1 1 1 1 1 5 1 6 6 1 1 1 1 1 1 1 1 1 1 1 1
065-040-200.1 CS40 2 2 1 1 1 1 1 1 1 4 1 5 5 1 1 1 1 1 1 1 1 1 1 1 1
080-050-125 CS40 1 1 1 1 1 1 1 1 1 6 1 7 7 1 1 1 1 1 1 1 1 1 1 1 1
080-050-160 CS40 1 2 1 1 1 1 1 1 1 6 1 8 8 1 1 1 1 1 1 1 1 1 1 1 1
080-050-160.1 CS40 1 2 1 1 1 1 1 1 1 22 1 27 27 1 1 1 1 1 1 1 1 1 1 1 1
080-050-200 CS40 2 2 1 1 1 1 1 1 1 6 1 7 7 1 1 1 1 1 1 1 1 1 1 1 1
080-050-200.1 CS40 2 2 1 1 1 1 1 1 1 22 1 27 27 1 1 1 1 1 1 1 1 1 1 1 1
100-065-125 CS40 1 2 1 1 1 1 1 1 1 7 1 9 9 1 1 1 1 1 1 1 1 1 1 1 1
050-032-250 CS50 3 4 2 2 2 2 2 2 2 3 2 4 4 2 2 2 2 2 2 2 2 2 2 2 2
050-032-250.1 CS50 3 4 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
065-040-250 CS50 3 4 2 2 2 2 2 2 2 9 2 11 11 2 2 2 2 2 2 2 2 2 2 2 2
065-040-250.1 CS50 3 4 2 2 2 2 2 2 2 8 2 10 10 2 2 2 2 2 2 2 2 2 2 2 2
065-040-315 CS50 4 5 2 2 2 2 2 2 2 9 3 11 11 3 3 2 2 2 2 2 2 2 2 2 2
065-040-315.1 CS50 4 5 2 2 2 2 2 2 2 8 3 10 10 3 3 2 2 2 2 2 2 2 2 2 2
080-050-250 CS50 3 4 2 2 2 2 2 2 2 6 2 7 7 2 2 2 2 2 2 2 2 2 2 2 2
080-050-250.1 CS50 3 4 2 2 2 2 2 2 2 23 2 28 28 2 2 2 2 2 2 2 2 2 2 2 2
080-050-315 CS50 4 6 2 2 2 2 2 2 2 11 3 13 13 3 3 2 2 2 2 2 2 2 2 2 2
080-050-315.1 CS50 4 6 2 2 2 2 2 2 2 10 3 12 12 3 3 2 2 2 2 2 2 2 2 2 2
100-065-160 CS50 5 7 2 2 2 2 2 2 2 11 4 13 13 4 4 2 2 2 2 2 2 2 2 2 2
100-065-200 CS50 6 4 2 2 2 2 2 2 2 11 4 14 14 4 4 2 2 2 2 2 2 2 2 2 2
100-065-250 CS50 7 5 2 2 2 2 2 2 2 7 3 9 9 3 3 2 2 2 2 2 2 2 2 2 2
125-080-160 CS50 5 4 2 2 2 2 2 2 2 12 4 15 15 4 4 2 2 2 2 2 2 2 2 2 2
125-080-200 CS50 8 4 2 2 2 2 2 2 2 12 3 16 16 3 3 2 2 2 2 2 2 2 2 2 2
125-080-200.1 CS50 8 4 2 2 2 2 2 2 2 24 3 29 29 3 3 2 2 2 2 2 2 2 2 2 2
125-080-250 CS50 7 6 2 2 2 2 2 2 2 12 3 16 16 3 3 2 2 2 2 2 2 2 2 2 2
125-100-160 CS50 8 5 2 2 2 2 2 2 2 13 3 17 17 3 3 2 2 2 2 2 2 2 2 2 2
125-100-200 CS50 8 5 2 2 2 2 2 2 2 13 3 17 17 3 3 2 2 2 2 2 2 2 2 2 2
100-065-315 CS60 9 6 3 3 3 3 3 3 3 12 3 16 16 3 3 3 3 3 3 3 3 3 3 3 3
125-080-315 CS60 9 8 3 3 3 3 3 3 3 12 3 16 16 3 3 3 3 3 3 3 3 3 3 3 3
125-080-400 CS60 10 9 3 3 3 3 3 3 3 13 5 17 17 5 5 3 3 3 3 3 3 3 3 3 3
125-100-250 CS60 11 6 3 3 3 3 3 3 3 13 3 17 17 3 3 3 3 3 3 3 3 3 3 3 3
125-100-315 CS60 9 8 3 3 3 3 3 3 3 13 3 17 17 3 3 3 3 3 3 3 3 3 3 3 3
16)
On pumps with casing wear ring only
17)
On pumps with casing wear ring and impeller wear ring only
18)
Depending on mechanical seal type
