KSB RDL - Description of the Product

RDL
8
Protecting Liquid
Thickness of applied layer
µm (in)
Drying Time Removal Manufacturer
TECTYL 506 80 to100 (.003 to .004) ½ up to 1 hour Gasoline/Benzene/Diesel Oil BRASCOLA
RUSTILO DW301 6 to 10 (.0002 to .0004) 1 up to 2 hours Gasoline/Benzene CASTROL
MOBILARMA 524 ≤ 6 (.0002) Does not dry Not necessary MOBIL OIL
Table 2 – Protecting liquids
4. Description of the product
Horizontal single stage, axially split volute casing pump with double entry radial impeller.
Drive shaft end of the pump can be fitted either on the left or right end side.
Flanges according to DIN or ANSI.
4.1 Technical specification
It is recommended for pumping clean or cloudy liquids in the following application:
- water supply
- drainage
- irrigation
- chemical and petrochemical industry
- air conditioning
- paper and cellulose industry
- fire-fighting
4.2 Designation
KSB RDL 250 - 500 A
Trade Mark
Model
Discharge nozzle diameter (mm)
Impeller nominal diameter (mm)
Impeller type
