KStar HPM3300E User Manual

14
(1) MAINTAIN AUXSWS : Maintenance breaker auxiliary contacts port, connect to PDU
AUX-MAINT port for detect maintenance breaker status.
(2) OUTPUT AUXSWS : Output breaker auxiliary contacts port, connect to PDU OUTPUT
AUX-OUTPUT port for detect output breaker status.
3.3 UPS module appearance
Front View
Side View
(1) Module fixed screw
(2) LED
