70
Appendix 1 Specifications
Model 60kVA 90kVA 80kVA 120kVA 100kVA 150kVA
Cabinet capacity (VA/W)
30k~60k
30k~60k
30k~90k
30k~90k
40k~80k
40k~80k
40k~120k
40k~120k
50k~100k
50k~100k
50k~150k
50k~150k
Module capacity (VA/W)
30k / 30k 40k / 40k 50k / 50k
Max. module number 2+1 3 2+1 3 2+1 3
Input
Phase 3 Phase 4 Wires and Ground
Rated Voltage 380/400/415Vac
Voltage Range
138~485Vac
◆ At 40°C: The UPS works at full load when the voltage is
323–485Vac and is derated load when the
voltage is 323–138Vac
◆ At 30°C: The UPS works at full load when the voltage is
305–485Vac and is derated load when the
voltage is 305–138Vac
Frequency Range 40Hz-70Hz
Power Factor ≥0.99
Current THDi ≤3%(100% nonlinear load)
Bypass Voltage Range
Max.voltage: 220V:+25 %( optional +10%, +15%, +20%);
230V:+20 %( optional +10%, +15%);
240V:+15 %( optional +10%);
Min. voltage:-45 %( optional -10%, -20%,-30%)
Frequency protection range: ±10%
Output
Phase 3 Phase 4 Wires and Ground
Rated Voltage 380/400/415Vac
Power Factor 1
Voltage Regulation ±1%
Frequency
Utility
Mode
±1%/±2%/±4%/±5%/±10%of the rated frequency(optional)
Battery
Mode
(50/60±0.1)Hz
Crest Factor 3:1
THD
≤2% with linear load
≤4% with non linear load
Overload
Inverter overload capability:
◆ 105% < load ≤ 110%: transfer to bypass mode after 60 min
◆ 110% < load ≤ 125%: transfer to bypass mode after 10 min
◆ 125% < load ≤ 150%: transfer to bypass mode after 1 min
Bypass overload capability:
◆ Temperature ≤ 30°C, load ≤ 135%: run for a long time
◆ Temperature ≤ 40°C, load ≤ 125%: run for a long time
◆ 1000% load: run for 100 ms
Battery
Voltage
Optional Voltage:
±180V/±192V/±204V/±216V/±228V/±240/±252/±264/±276/±288/±300
Vdc(30/32/34/36/38/40/42/44/46/48/50pcs optional)
360Vdc~600Vdc (30~50 pcs, 36 pcs default, 36 and 50 pcs no power
derating; 32~34 pcs output power factor 0.9; 30 pcs output power
factor 0.8 ;)
Module charge current
(A)
max.
20A
Transfer Time
Utility to Battery : 0ms; Utility to bypass: 0ms
Protection Short Circuit Turn to bypass
