22
Battery input
connector
Crimped OT
terminals
M10 11mm
26N•m
Output
connecto
r
Crimped OT
terminals
M10 11mm
26N•m
Grounding
connecto
r
Crimped OT
terminals
M10 11mm
26N•m
120k
Mains input
connector
Crimped OT
terminals
M10 11mm
26N•m
Bypass input
connector
Crimped OT
terminals
M10 11mm
26N•m
Battery input
connector
Crimped OT
terminals
M10 11mm
26N•m
Output
connecto
r
Crimped OT
terminals
M10 11mm
26N•m
Grounding
connecto
r
Crimped OT
terminals
M10 11mm
26N•m
150k
Mains input
connector
Crimped OT
terminals
M10 11mm
26N•m
Bypass input
connector
Crimped OT
terminals
M10 11mm
26N•m
Battery input
connector
Crimped OT
terminals
M10 11mm
26N•m
Output
connecto
r
Crimped OT
terminals
M10 11mm
26N•m
Grounding
connecto
r
Crimped OT
terminals
M10 11mm
26N•m
3.7.3 Recommended input front-end and output back-end circuit breakers
UPS capacity
Component Specifications
80k
Mains input breaker
160A 3P
Bypass input breaker
160A 3P
Output breaker
160A 3P
Battery breaker
250A 3P
100k
Mains input breaker
200A 3P
Bypass input breaker
200A 3P
Output breaker
200A 3P
Battery breaker
320A 3P
120k
Mains input breaker
250A 3P
Bypass input breaker
250A 3P
Output breaker
250A 3P
Battery breaker
400A 3P
150k
Mains input breaker
320A 3P
Bypass input breaker
320A 3P
