KStar HPM3300E User Manual

59
Lightning arrester(SPD) : Enable or disable SPD detection. The default value is Disable.
Generator (GEN) : Enable or disable GEN detection. The default value is Disable.
OUT01~OUT06: Output dry contact port, modify on the LCD, the default value is
Disable.The output port can set to normally closed or normally
opend,The default value is normally opened.
Setting value:
No. Item No. Item
1 URGENT_ALARM 8 BATTERY_SUPPLY
2 MINOR_ALARM 9 NO_SUPPLY
3 MAIN ABNORMAL 10 ECO_MODE
4 BATTERY_LOW_VOLT 11 MAINT_CLOSE
5 BATTERY_SELFCHECK 12 OIL_MACHINE_CONTROL
6 MAIN_SUPPLY 13 SYS_MAINT_OPEN
7 BYPASS_SUPPLY 14 SYS_OUPPUT_OPEN
