KStar HPM3300E User Manual

68
No Fault Cord UPS Alarm Warning Buzzer LED
27 05E DC Component Fault Once per 2 seconds Fault LED lit
28 061 DC bus abnormal Beep continuously Fault LED lit
29 064 INV DSP Power Fault Beep continuously Fault LED lit
30 067 INV Over Temperature Twice per second Fault LED lit
31 068 Load Sharing Fault Twice per second Fault LED lit
32 06A Cabinet mode Fault Beep continuously Fault LED lit
33 06B Fuse Broken Beep continuously Fault LED lit
34 081 Par. cable Fault Twice per second Fault LED lit
35 086 ECU Insert Fault Once per 2 seconds Fault LED lit
36 088 ECU Power Fault Beep continuously Fault LED lit
37 08B ECU Comm. Fault Beep continuously Fault LED lit
38 08D ECU Initializes Fault Once per 2 seconds Fault LED blinking
39 091
Bypass SCR Broken
Beep continuously Fault LED lit
40 0C2 Beep continuously Fault LED lit
41 094
Bypass SCR short
Beep continuously Fault LED lit
42 0C5 Beep continuously Fault LED lit
43 097
BPS Over Temperature
Beep continuously Fault LED lit
44 0CF Beep continuously Fault LED lit
45 09A Output CT Reverse Beep continuously Fault LED lit
46 09B Dry-contact Power Fault Beep continuously Fault LED lit
47 09C Dry-contact Comm. Fault Beep continuously Fault LED lit
48 09D Bypass Feedback Fault Beep continuously Fault LED lit
49 0C1 BYS Par.cable Fault Beep continuously Fault LED lit
50 0C8 BPS Comm. Fault Beep continuously Fault LED lit
51 0CA Bypass Initializes Fault Beep continuously Fault LED lit
52 0CD Bypass connected fault Beep continuously Fault LED lit
53 0D2 Bypass Fan Fault Beep continuously Fault LED lit
Alarm Information
No Alarm Cord UPS Alarm Warning Buzzer LED
1 103 Battery Over Voltage Once per second Alarm LED lit
2 104 BAT Low Pre-warning Once per second Alarm LED lit
3 105 Battery Reverse Twice per second Alarm LED lit
4 106 Battery EOD Once per second Alarm LED lit
5 107 Battery Voltage low Once per second Alarm LED lit
6 108 No Battery Once per second Alarm LED lit
7 109 Input Phase Reverse Once per second Alarm LED lit
8 10A Input N-Line lost Twice per second Alarm LED lit
9 10B Mains Freq. Abnormal Once per 2 seconds Alarm LED lit
10 10C Mains Volt. Abnormal Once per 2 seconds Alarm LED lit
11 10D REC Comm. Error Once per 2 seconds Alarm LED lit
12 10E Mains input lost Once per 2 seconds Alarm LED lit
13 10F Set Data Err. Once per 2 seconds Alarm LED lit
14 121 INV Par. cable abnormal Once per 2 seconds Alarm LED lit
15 125 INV Overload Once per 2 seconds Alarm LED lit
16 126 INV not synchronized Beep continuously Alarm LED lit
17 12A INV Set Data Err Once per 2 seconds Alarm LED lit
18 129 INV Comm. Error Once per 2 seconds Alarm LED lit
19 141 Bypass Switch to Num Once per 2 seconds Alarm LED lit
20 142 Unit quantity mismatch Once per 2 seconds Alarm LED lit
21 143 Parallel Overload Once per 2 seconds Alarm LED lit
