31
31
Coming to over load due to
inverter off
When the inverter is turned off manually, the load will
exceed the power capacity.
32
Coming to Interval transfer
due to inverter off
When the inverter is turned off manually, the load will
exceed the power capacity.
33
Inverter invalid due to
over load
The load exceeds the capability of the single or parallel
modules.
34
Inverter Master
It indicates the Master Inverter.
35
Transfer Times-out
Latched load transfer to bypass as a result of too many
successive transfers within the current hour. Automatic
reset attempt within the next hour.
36
UPS In shutdown Due To
Overload.
The load exceeded the power capacity. The UPS has
been shutdown
37
UPS In Bypass Due To
Overload.
The load exceeded the power capacity. The UPS has
switched to Bypass Mode.
38
Parallel in Bypass
The parallel system has switched to bypass mode
39
LBS Activated
LBS has been activated.
40
Lightning Protection
Lightning protector has been activated.
41
Battery low to UPS OFF
battery voltage lower than protection point
42
UPS timing on
UPS on at certain time
43
UPS timing OFF
UPS off at certain time
44
timing self-test start
start to self-test at certain time
45
Stop self-test
self-test stops
46
manual OFF
turn off UPS manually
47
remote OFF
turn off UPS remotely
48
module connected
module is connected
49
module removed
module is removed
Alarm Information
No.
Display me s sage
Meaning
1
Rectifier Fault
Rectifier detected faulty. Rectifier and inverter and
charger shut down.
2
Rectifier Over Temperature
The temperature of heatsink is too high to keep the
rectifier running. Charger and inverter shut down.
3
Inverter Over temperature
The temperature of the inverter heatsink is too high to
keep inverter running.
4
Rectifier over-current
Rectifier failure due to over-current
5
Input thyristor failure
Failure of input thyristor
6
Battery discharge thyristor
failure
Failure of battery discharge thyristor
7
Battery charge thyristor failure
Failure of battery charge thyristor
8
Fan fault
At least one of the cooling fans fails. Rectifier and
inverter and charger shut down.
9
DC Bus over-voltage
Rectifier, inverter and battery converter are shutdown due
to high DC bus voltage.
10
DC Bus under-voltage
Rectifier, inverter and battery converter are shutdown
due to low DC bus voltage.
11
DC bus unbalance
If the difference between positive DC bus and negative
DC bus exceeds 30V, this warning shall occur.
12
Soft start fault
Rectifier could not be started due to low DC bus voltage
13
Input Neutral line missing
If Input Neutral line is missing or disconnected while the
UPS is in operation, the UPS will generate Neutral line
failure alarm and go into Battery mode.
14
Battery Reverse
The polarity of the battery is reversed.
15
No Battery
Battery is disconnected
16
Positive Battery Charger
fault
The positive battery Charger is fault. The charger will
be shut down.
