KStar YDC9300-RT - UPS Module Specifications

36
Overload Capacity
Load≤110%，60min，≤125%，last 10min，≤150%last
1min，≥150% shut down UPS immediately
THD
≤2% with linear load
≤5% with non linear load
Efficiency
Normal mode≥90%
Comunicatio
n Interface
UPS cabinet
RS232，Optical coupler dry contact，RS485, SNMP
card（optional），Centralized monitoring card（optional）
UPS module
RS232
Battery
Voltage
±96V\±108V\±120V DC; battery quantity(optional)
Charge Current(A)
UPS
cabinet
Maximum current 30A
Maximum current 60A
UPS
module
Maximum current 6A
Backup time
Depends on the capacity of external batteries
Operating
Environment
Temperature
0℃～40℃
Humidity
0～95% non condensing
Storage temperature
-25℃～55℃
Altitude
< 1500m
Other
Unit
Dimensions(W*D*H
)
UPS
cabinet
600*840*1400mm
600*840*2000mm
UPS
module
443x580x131 mm
Weight (Kg)
UPS
cabinet
150
180
UPS
module
4KVA: 21
6KVA: 23
10KVA: 25
Industry Standard
CE,EN/IEC 62040-2,EN/IEC 62040-1-1
Appendix 2 UPS message table
1. The Inner Code is applied to This Series. The following format block is Inner Code display on LCD：
AAAA–AAAA BBBB-BBBB EEFF
CCCC-CCCC DDDD-DDDD
2. The part of Inner Code means
AAAA-AAAA（Rectifier State）：
Byte 1
8
9
A
B
C
D
E
F
Int. Input Switch closed
4
5
6
7
C
D
E
F
Rectifier Activated
2
3
6
7
A
B
C
E
F
Emergency Power off
1
3
5
7
9
B
D
F
Rectifier current Limt
