KStar YDC9300-RT - Options

33
45
Feedback protection
This UPS is fitted with a voltage free contact closure
signal for use with an external automatic disconnect
device (by others) to protect against back-feeding
voltage into the incoming bypass supply
46
Ext. Fire Alarm
External fire detector has been activated.
47
Ext. Smoke Alarm
External smoke detector has been activated.
48
battery damaged
battery has been damaged, this warning shall occur.
49
battery over-temperature
battery over-temperature, this warning shall occur.
50
model set wrong
Model setting of the UPS is incorrect.
4.5 Options
Network Management Card with Environmental Monitoring
CAUTION!
For network management configuration and use, refer to the separate user
manual - Network Management Card with Environmental Monitor - shipped with the
CARD.
Network Management Card replacement
1：Intelligent Network Port 2：SNMP port
SNMP card: internal SNMP / external SNMP optional
◆ Loosen the 2 torque screws (on each side of the card).
◆ Carefully pull out the card. Reverse the procedure for re-installation
The slot called SNMP supports the MEGAtec protocol. We advise that NetAgent II-3 port is
also a tool to remotely monitor and manage any UPS system
the overview of the SNMP card
