Instruction Manual of
Programmable Power Controller (KT-PPC)
REV
1.6E
PAGE : 15 OF 25
Doc No: TIR9402-30-D01
210*297(mm) KTE CO., LTD TI-06(R0)
4.3. TERMINAL OUTPUT 03
O
U
T
P
U
T
0
3
01
+24V POWER SUPPLY
02
+24V
03
+24V
04
+24V
05
GND POWER SUPPLY
06
GND
07
GND
08
GND
09
Unused
10
Unused
11
Unused
12
Unused
13
Unused
14
Unused
15
Unused
16
Unused
17
Unused
18
Unused
19
Unused
20
Unused
21
PPC NORMAL Contact(A-C)
22
23
No.1 ACB Close Contact(A-C)
24
25
No.2 ACB Close Contact(A-C)
26
27
No.3 ACB Close Contact(A-C)
28
29
No.1 ACB Open Contact(A-C)
30
31
No.2 ACB Open Contact(A-C)
32
33
No.3 ACB Open Contact(A-C)
34
35
Heavy Load Contact(A-C)
36
