1.2. GENERAL SPECIFICATIONS
Item
Description
General
Specifications
Power Source
DC 24V ±20%
Current Consumption
Max 1A / DC 24V
Temperature range
Operating temp : 0 ~ 55℃
Storing temp : -10℃ ~ 70℃
Weight
Approx. 5Kg
Communication
RS-232c serial 1 port
CPU
Specification
Control system
Intel 80c196kc 16Bit microcomputer
Program system
Assemble description system
Program memory
External 32K bytes(27c256) EPROM
Memory
Internal 256bytes RAM
External 32K bytes(28c256) EEPROM
Input / Output
Specification
Input signal
Digital input : 48 Channel (on/off)
Analog input : 5 Channel (4 ~ 20mA)
Output signal
Contact output : 8 Channel('a" contact)
Signal output : 32 Channel(positive signal)
