6.2. Panel Switch using method
-
-
-
-
: 감소
1
2
3
+
+
+
+
: 증가
SW3 (0～9)
SW2 (0～9)
SW1 (0～9)
Using the panel switch attached to the front, we can recognize internal each data setting value and
status.
Using method is same the following.
(The following can be applied to only KT-PPC-A type model)
SW1
SW2
SW3
CONTENT
0
0
0
run : Normal operation
1
0
X
Unused
1
X
No.1 Generator power (Kw)
2
X
No.2 Generator power (Kw)
3
X
No.3 Generator power (Kw)
4
X
Generator total power (Kw) < ACB close>
5
X
Internal +5V power setting (VR1)
6
X
Internal +12V power setting (VR2)
7
X
Internal -12V power setting (VR3,4)
8
X
Unused
9
X
Unused
2
0
X
Unused
1
X
No.1 Generator capacity ratio (%)
2
X
No.2 Generator capacity ratio (%)
3
X
No.3 Generator capacity ratio (%)
4
X
Generator total power (%)
5
X
Unused
6
X
Unused
7
X
Unused
8
X
Unused
9
X
Unused
※ X : 0 ～ 9
