Instruction Manual of
Programmable Power Controller (KT-PPC)
REV
1.6E
PAGE : 17 OF 25
Doc No: TIR9402-30-D01
210*297(mm) KTE CO., LTD TI-06(R0)
5. INPUT / OUTPUT REFERENCE TABLES
PPC I/O TABLE
TYPE : INPUT 00 No. 1/4
TER.NO.
SIGNAL NAME
SYMBOL
I
N
P
U
T
00
01
ANALOG INPUT 1 (+) 4 - 20mA
02
ANALOG INPUT 1 (-) 4 - 20mA
03
ANALOG INPUT 2 (+) 4 - 20mA
04
ANALOG INPUT 2 (-) 4 - 20mA
05
ANALOG INPUT 3 (+) 4 - 20mA
06
ANALOG INPUT 3 (-) 4 - 20mA
07
ANALOG INPUT 4 (+) 4 - 20mA
08
ANALOG INPUT 4 (-) 4 - 20mA
09
ANALOG INPUT 5 (+) 4 - 20mA
10
ANALOG INPUT 5 (-) 4 - 20mA
11
GND
12
GND
13
F.G (Frame Ground)
14
F.G
15
X
16
X
17
X
18
X
19
X
20
X
21
X
22
X
23
X
24
X
25
No.1 GEN AUTO MODE SELECT
INP 01.0
143A AUTO
26
No.2 GEN AUTO MODE SELECT
INP 01.1
243A AUTO
27
No.3 GEN AUTO MODE SELECT
INP 01.2
343A AUTO
28
No.1 GEN ABNORMAL RESET
INP 01.3
3R-128
29
No.2 GEN ABNORMAL RESET
INP 01.4
3R-228
30
No.3 GEN ABNORMAL RESET
INP 01.5
3R-328
31
No.1 GEN (ENG. START SW.)
INP 01.6
3-106 CS11
32
No.2 GEN (ENG. START SW.)
INP 01.7
3-206 CS21
33
No.3 GEN (ENG. START SW.)
INP 02.0
3-306 CS31
34
No.1 GEN (ENG. STOP SW.)
INP 02.1
3-105 STOP
35
No.2 GEN (ENG. STOP SW.)
INP 02.2
3-205 STOP
36
No.3 GEN (ENG. STOP SW.)
INP 02.3
3-305 STOP
