Instruction Manual of
Programmable Power Controller (KT-PPC)
REV
1.6E
PAGE : 18 OF 25
Doc No: TIR9402-30-D01
210*297(mm) KTE CO., LTD TI-06(R0)
PPC I/O TABLE
TYPE : INPUT 01 No. 2/4
TER.NO.
SIGNAL NAME
SYMBOL
I
N
P
U
T
01
01
No.1 GEN (ACB OPEN SW.)
INP 02.4
CS11 OPEN
02
No.2 GEN (ACB OPEN SW.)
INP 02.5
CS21 OPEN
03
No.3 GEN (ACB OPEN SW.)
INP 02.6
CS31 OPEN
04
AUTO LOAD SHARING
INP 02.7
43-77 AUTO
05
No.1 GEN READY TO START
INP 03.0
ENG1 READY
06
No.2 GEN READY TO START
INP 03.1
ENG2 READY
07
No.3 GEN READY TO START
INP 03.2
ENG3 READY
08
No.1 GEN RUN
INP 03.3
114X RUN
09
No.2 GEN RUN
INP 03.4
214X RUN
10
No.3 GEN RUN
INP 03.5
314X RUN
11
No.1 GEN STOP
INP 03.6
105X STOP
12
No.2 GEN STOP
INP 03.7
205X STOP
13
No.3 GEN STOP
INP 04.0
305X STOP
14
No.1 GEN ACB CLOSE
INP 04.1
CB1 CLOSE
15
No.2 GEN ACB CLOSE
INP 04.2
CB2 CLOSE
16
No.3 GEN ACB CLOSE
INP 04.3
CB3 CLOSE
17
GEN. VOLTAGE BUILD UP
INP 04.4
84G
18
X
19
X
20
PC RUN
PC RUN
21
No.1 GEN ACB TRIP (OCR. RPR)
INP 05.0
CB1 TRIP
22
No.2 GEN ACB TRIP (OCR. RPR)
INP 05.1
CB2 TRIP
23
No.3 GEN ACB TRIP (OCR. RPR)
INP 05.2
CB3 TRIP
24
HEAVY LOAD (PWC)
INP 05.3
HEAVY LOAD
25
LIGHT LOAD (PWC)
INP 05.4
LIGHT LOAD
26
HIGH POWER (PWC)
INP 05.5
HIGH LOAD
27
ACB OPEN COMMAND (PWC)
INP 05.6
O POWER
28
BUS ABNORMAL (PWC)
INP 05.7
BUS ABN
29
ACB NON CLOSE (ASD)
INP 06.0
NON CLOSE
30
AUTO SYNCHRO FAIL (ASD)
INP 06.1
SYNCH FAIL
31
PREF. TRIP
INP 06.2
PREF TRIP
32
BUS NO VOLT
INP 06.3
BUS NO VOLT
33
REQU.1 (BIG MOTOR START)
INP 06.4
34
REQU.2 (BIG MOTOR START)
INP 06.5
35
REQU.3 (BIG MOTOR START)
INP 06.6
36
X
