-10-
DC power input Screwed euro terminal block: 2 pairs of +/- contacts
Operating Input Voltages +7 ~ +60VDC (General applications)
+45 ~ +57VDC (PoE applications)
Power consumption 9W max. (Full load with no PoE support)
150W max. (Full load with 4 PoE max. output)
Alarm relay output 2 terminal contacts AR+/AR- (30VDC/1A max. or 120VAC/0.5A max.)
Alarm events Power failure, Specific port link fault (software configured), OPA
* Warning: The -48VDC power supply is not supported.
Mechanical
Dimension (base) 140 x 106 x 42 mm (HxDxW)
Housing Enclosed metal with no fan
Mounting Din-rail mounting, Panel mounting (optional)
Environmental
Operating Temperature Typical -30
℃ ~ +70℃*
Storage Temperature -40
℃ ~ +85℃
Relative Humidity 5% ~ 90% non-condensing
* +60
℃
~ +70
℃
with 1m/s air flow
Electrical Approvals
FCC Part 15 rule Class A
CE EMC, CISPR11 Class A
Safety / LVD IEC 60950-1
