Page #9 background imageLoading...
Page #9 background image
-9-
Console Port
Interface RS-232, DTE type
Connector Shielded RJ-45
Switch Functions
MAC Addresses Table 8K entries
Forwarding & filtering Non-blocking, full wire speed
Switching technology Store and forward
Maximum packet length 9.6K bytes
IP Multicast groups 8192 supported
Flow control IEEE 802.3x pause frame base for full duplex operation
Back pressure for half duplex operation
Power over Ethernet PSE Function (KGS-1060-HP)
PSE Ports Port 1 ~ Port 4
Power output pins Positive of power voltage: pin 1,2
Negative of power voltage: pin 3,6
Standard IEEE 802.3at
Classification PD Class 0 ~ 4 detection
Power Delivery 35W max. (per port) at port output for Cat.5 distance up to 100 meters
Protection Under voltage protection
Over voltage protection
Over current detection
Powered via Power over Ethernet (KGS-1060)
PD Port Port 2
PoE Standard IEEE 802.3af PoE PD (Powered Device)
PSE Support IEEE 802.3af & 802.3at PSE
Power Classification Class 3
Input Voltage (V
poe
) 36 ~ 57VDC via Cat.5
Power reception pins Positive of PoE power voltage: pin 1,2,4,5
Negative of power voltage: pin 3,6,7,8
Terminal Block Connector
