ENGLISH
17
Check/set distance of the magnetic sensor
The distance between magnet 2 and sensor 1 must be 2-4 mm, otherwise
malfunctions on the speedometer might occur.
This distance can be corrected by screwing in or off the sensor
1.
WHEEL CIRCUMFERENCE „WS“
1. make sure that the indication "TRP" is
active and push the button on the
back approx. 5 seconds ("WS"
appears)
2. use the right button to select the
position to be changed
3. push the left button until the right
figure is showed in the display
4. repeat nos. 2 + 3 until correct
wheel circumference is indicated
5. push the button on the back
for approx. 1 second to termi-
nate the setting procedure
5 sec
1 sec
mm x 3,14
km/h:
WS = mm x 3,14
mp/h:
WS = (mm x 3,14) : 1,61
1
1
2
Wheel circumference with standard tires
17” = 1882 mm / 21” = 2205 mm
