ENGLISH
13
OPERATION INSTRUMENTS
»
Fuel tap
OFF In this position the fuel tap is closed. No fuel may flow to the
carburetor.
ON When using the motorcycle, the rotating handle must be set to the ON
position. Now fuel may flow to carburetor. In this position the tank emp-
ties down to the fuel reserve of approx. 2,5 liters.
RES The reserve tank, approximately 2,5 liters, cannot be tapped until the
rotating handle is turned to the RES position. Fill the tank as soon as
possible and remember to turn the rotating handle back to the ON posi-
tion so that you will have backup fuel next time, too.
Choke
If you pull the choke button [1] out as far as possible, a bore in the carbure-
tor will be opened through which the engine may take in additional fuel. The
result is a „fat“ fuel-air mixture of the type needed for cold starts.
To deactivate the choke, push the choke button back into its basic position.
Hot start device
If you pull the hot start device [2] out as far as possible, a bore in the carbu-
retor will be opened through which the engine may take in additional air. The
result is a „lean“ fuel-air mixture of the type needed for hot starts.
To deactivate the hot start device, push the hot start button back into its basic
position.
Shift lever
The shift lever is mounted on the left side of the engine. The position of the
gears is shown in the illustration. Neutral position is located between first and
second gear.
Kickstarter
The kickstarter is mounted on the left side of the engine. Its upper part can
be swivelled.
RES OFF ON
2,3,4,5
1
N
1
2
