KTM 690 Enduro R 2021 Setup Instructions

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 690 Enduro R 2021 Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid-cooled
Compression Ratio	12.7:1
Starter	Electric starter
Front Tire	90/90-21
Rear Tire	140/80-18
Seat Height	910 mm
Power	74 hp (55 kW) @ 8, 000 rpm
Torque	73.5 Nm
Frame	Chromoly steel trellis frame
Front Suspension	WP XPLOR USD, 48 mm
Rear Suspension	WP XPLOR monoshock
Front Brake	Single 300 mm disc
Rear Brake	Single 240 mm disc
ABS	Bosch 9.1 MP (disengageable)
Front Wheel	21 inch
Rear Wheel	18 inch
Wheelbase	1504 mm
Ground Clearance	270 mm
Fuel Tank Capacity	13.5 l
Dry Weight	146 kg
