4 TECHNICAL DATA 14

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701™

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, connection lever on frame M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, foot brake lever M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front footrest bracket M8 25 Nm (18.4 lbf ft) –

Screw, fuel tank bracket M8 15 Nm (11.1 lbf ft) –

Screw, fuel tank, bottom M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, fuel tank, top M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, grab handle M8 10 Nm (7.4 lbf ft) –

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, heel protector M8x12 5 Nm (3.7 lbf ft) Loctite

243™

Screw, license plate holder, top M8 20 Nm (14.8 lbf ft) –

Screw, main silencer clamp M8 12 Nm (8.9 lbf ft) Copper paste

Screw, main silencer holder M8 25 Nm (18.4 lbf ft) –

Screw, main silencer holder on fuel

tank

M8 25 Nm (18.4 lbf ft) –

Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft) –

Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, spring holder on side stand

bracket

M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, steering stem M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –

Engine carrying screw M10 45 Nm (33.2 lbf ft) Loctite

243™

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, engine bearer on frame M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite

243™

Screw, top shock absorber M10 45 Nm (33.2 lbf ft) Loctite

243™

Banjo bolt, brake line M10x1 20 Nm (14.8 lbf ft) –

Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft) Loctite

243™

Screw, swingarm pivot M12 80 Nm (59 lbf ft) –

Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) Copper paste

Nut, linkage lever on swingarm M14x1.5 100 Nm (73.8 lbf ft) –

Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft) –

Screw, bottom steering head M20x1.5 60 Nm (44.3 lbf ft) Loctite

243™

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –

Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft) –

Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) –

Questions and Answers:

Need help?

Do you have a question about the KTM 690 SMC R 2016 Series and is the answer not in the manual?

KTM 690 SMC R 2016 Series Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	690 cc
Bore x Stroke	102 mm x 84.5 mm
Compression Ratio	12.6:1
Cooling	Liquid cooled
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Fuel Tank Capacity	13.5 liters
Power	67 hp
Fuel System	Keihin EFI with 46mm throttle body
Clutch	hydraulically operated
Rear Suspension	WP monoshock
Front Brake	Brembo 4-piston radial fixed caliper, brake disc Ø 320 mm
Rear Brake	Brembo single-piston caliper, 240 mm disc
ABS	Bosch two-channel ABS (disengageable)
