20 TECHNICAL DATA
120
Standard 15 clicks
Sport 12 clicks
Spring preload 11 mm (0.43 in)
Spring rate
Weight of rider: < 45 kg (< 99 lb.) 35 N/mm (200 lb/in)
Weight of rider: 45 … 55 kg (99 … 121 lb.) 40 N/mm (228 lb/in)
Weight of rider: > 55 kg (> 121 lb.) 45 N/mm (257 lb/in)
Spring length 215 mm (8.46 in)
Gas pressure 10 bar (145 psi)
Static sag 30 mm (1.18 in)
Riding sag 120 mm (4.72 in)
Fitted length 397 mm (15.63 in)
Shock absorber fluid ( p. 123) SAE 2.5
20.9 Chassis tightening torques
Spoke nipple M4.5 5 Nm (3.7 lbf ft)
Screw, main silencer M5 7 Nm (5.2 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Pin, front brake M6 8 Nm (5.9 lbf ft)
Pin, rear brake M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw for throttle grip M6 5 Nm (3.7 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, front fender M6 6 Nm (4.4 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Start number plate screw M6 4 Nm (3 lbf ft)
Nut, rim lock M8 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, engine brace M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, rear brake caliper M8 18 Nm (13.3 lbf ft)
Loctite
®
243™
Screw, rear sprocket M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
