KTM 890 ADVENTURE R 2023 Setup Instructions

3 WORK
12
3.8 Removing the right side cover
Preparatory work
– Remove the seat. ( p. 9)
F03295-10
Main work
–
Remove the side cover from the rubber bushings in areas
A
and
B
.
– Pull off the right side cover sideways and remove it toward the
front.
3.9 Opening the storage compartment on the right
Preparatory work
– Remove the seat. ( p. 9)
– Remove the right side cover. ( p. 12)
F03287-10
Main work
–
Lift the elastic fastener
1
and detach in area
A
.
– Open storage compartment.

KTM 890 ADVENTURE R 2023 Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Front Suspension	WP XPLOR-USD, Ø 48 mm
Bore x Stroke	90.7 mm x 68.8 mm
Compression Ratio	13.5:1
Fuel System	Electronic Fuel Injection
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 2 oil pumps
Frame	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Power	105 hp (77 kW) @ 8, 000 rpm
Torque	100 Nm
Fuel Tank Capacity	20 liters
Seat Height	880 mm (34.6 in)
Dry Weight	196 kg (432 lb)
Rear Suspension	WP XPLOR PDS shock absorber
Front Brake	2x radially mounted 4-piston calipers
Rear Brake	2-piston floating caliper
ABS	Bosch 9.1 MP (incl. Cornering-ABS and offroad mode)
Wheels Front	21"
Wheels Rear	18"
Chain	520
Steering Head Angle	63.5°
Ground Clearance	263 mm
