KTM 890 ADVENTURE R 2023 - 4 TECHNICAL SPECIFICATIONS; 4.1 chassis tightening torques

TECHNICAL SPECIFICATIONS 4
25
4.1 chassis tightening torques
Brake fluid reservoir cover, front - 2 Nm (1.5 lbf ft)
Brake fluid reservoir cover, rear - 1.5 Nm (1.11 lbf ft)
Compensating tank cover - 1.1 Nm (0.81 lbf ft)
Nut, valve ISO 10V2 12 Nm (8.9 lbf ft)
Loctite
®
2701™
Remaining screws, chassis EJOTPT
®
K45x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, inside cover on radiator EJOT PT
®
K50x18 4.5 Nm (3.32 lbf ft)
Screw, tail light EJOT DELTA PT
®
45x12‑Z 1.5 Nm (1.11 lbf ft)
Socket for electrical accessories - 4 Nm (3 lbf ft)
Throttle valve body hose clamp - 2.8 Nm (2.07 lbf ft)
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft)
Remaining screws, chassis M4 3 Nm (2.2 lbf ft)
Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw for throttle grip M5 3.5 Nm (2.58 lbf ft)
Screw, air filter box M5 3 Nm (2.2 lbf ft)
Screw, brake fluid reservoir for rear
brake
M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, brake line holder on link
fork
M5 1 Nm (0.7 lbf ft)
Screw, combination instrument M5 1 Nm (0.7 lbf ft)
Screw, combination switch, left M5 2 Nm (1.5 lbf ft)
Screw, combination switch, right M5 5 Nm (3.7 lbf ft)
Screw, engine sprocket cover M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, foot brake lever stub M5 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fork protector M5x12 5 Nm (3.7 lbf ft)
Screw, fork protector M5x17 5 Nm (3.7 lbf ft)
Screw, fuel level sensor M5 3 Nm (2.2 lbf ft)
Screw, fuel tank insert M5 3 Nm (2.2 lbf ft)
Screw, headlight mask M5 3.5 Nm (2.58 lbf ft)
Screw, headlight mask intermedi-
ate part
M5 3.5 Nm (2.58 lbf ft)
Screw, heat guard M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, instrument support on
mask support, front
M5 5 Nm (3.7 lbf ft)
Screw, instrument support on
mask support, rear
M5 5 Nm (3.7 lbf ft)
