KTM 890 ADVENTURE R 2023 - Page 28

4 TECHNICAL SPECIFICATIONS
26
Screw, license plate holder M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, lower rear panel M5 3 Nm (2.2 lbf ft)
Screw, mask support M5 5 Nm (3.7 lbf ft)
Screw, mask support cover M5 3.5 Nm (2.58 lbf ft)
Screw, side stand sensor M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, splash protector M5 2.8 Nm (2.07 lbf ft)
Screw, trim M5 3 Nm (2.2 lbf ft)
Spoke nipple M5 6 Nm (4.4 lbf ft)
Hand guard fitting M6 6 Nm (4.4 lbf ft)
Nut, foot brake lever adjustment M6 6 Nm (4.4 lbf ft)
Nut, hand brake lever M6 Attach torque to nut.
10 Nm (7.4 lbf ft)
Nut, push rod, foot brake lever M6 6 Nm (4.4 lbf ft)
Nut, shift rod M6 6 Nm (4.4 lbf ft)
Nut, shift rod M6LH 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw activated carbon filter on
retaining bracket
M6 8 Nm (5.9 lbf ft)
Screw cap, fuel tank cover M6 8 Nm (5.9 lbf ft)
Screw, 6-D sensor M6 5 Nm (3.7 lbf ft)
Screw, ABS module M6 8 Nm (5.9 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, battery cover attachment M6 5 Nm (3.7 lbf ft)
Screw, battery holding bracket M6 4.5 Nm (3.32 lbf ft)
Screw, battery terminal M6 4.5 Nm (3.32 lbf ft)
Screw, brace for mask support
center part
M6 3 Nm (2.2 lbf ft)
Loctite
®
243™
Screw, brake assembly M6 5 Nm (3.7 lbf ft)
Screw, cable on starter motor M6 5 Nm (3.7 lbf ft)
Screw, cable on starter relay M6 4.5 Nm (3.32 lbf ft)
Screw, clutch assembly M6 5 Nm (3.7 lbf ft)
Screw, cross member in rear M6x13 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, cross member in rear M6x12 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, engine guard M6x8 8 Nm (5.9 lbf ft)
Screw, engine guard M6x10 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, engine guard retaining
bracket
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, exhaust clamp on main
silencer
M6 8 Nm (5.9 lbf ft)
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
