Screw, footrest bracket, rear M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, front wheel speed sensor M6 6 Nm (4.4 lbf ft)
Screw, fuel pump M6 6 Nm (4.4 lbf ft)
Screw, fuel tank clamp M6 3 Nm (2.2 lbf ft)
Screw, fuel tank cover M6x12 8 Nm (5.9 lbf ft)
Screw, fuel tank cover M6x22 8 Nm (5.9 lbf ft)
Screw, fuel tank spoiler attach-
ment
M6 4 Nm (3 lbf ft)
Screw, fuel tap M6 6 Nm (4.4 lbf ft)
Screw, ground wire on frame M6 6 Nm (4.4 lbf ft)
Screw, ground wire to starter motor M6 10 Nm (7.4 lbf ft)
Screw, ignition lock (tamper-proof
screw)
M6 Tighten until the head tears off.
Loctite
®
243™
Screw, magnetic holder on side
stand
M6 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, mask support on frame M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, mask support on steering
head
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, presilencer exhaust clamp M6 8 Nm (5.9 lbf ft)
Copper paste
Screw, radiator bracket, bottom M6 5 Nm (3.7 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear wheel speed sensor M6 6 Nm (4.4 lbf ft)
Screw, seat fixing M6 6 Nm (4.4 lbf ft)
Screw, seat lock M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift rod M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift shaft deflector on shift
shaft
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, voltage regulator M6 6 Nm (4.4 lbf ft)
Foot brake lever, fitting M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Hand guard screw M8 25 Nm (18.4 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Pin, rear brake caliper M8 22 Nm (16.2 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, engine fixing arm linkage
bracket
M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
