10 TUNING THE CHASSIS 79
Guideline
Compression damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Info
Turn clockwise to increase damping; turn counterclockwise to reduce damping.
– Mount protection covers 1.
10.3 Adjusting the rebound damping of the fork
Info
The hydraulic rebound damping determines the fork rebound behavior.
100534-10
– Turn adjusting screws 1 clockwise all the way.
Info
The adjusting screws are located at the top end of the fork legs.
Make the same adjustment on both fork legs.
– Turn back counterclockwise by the number of clicks corresponding to the fork type.
