4 TECHNICAL DATA 12

Screw, front mask structure on head-

light bracket

M6 6 Nm (4.4 lbf ft) –

Screw, front seat fixing M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler M6 7 Nm (5.2 lbf ft) –

Screw, front spoiler retaining bracket,

rear

M6 6 Nm (4.4 lbf ft) –

Screw, front spoiler retaining bracket,

rear, on engine

M6 9 Nm (6.6 lbf ft) –

Screw, front spoiler, right, on footrest

bracket

M6 7 Nm (5.2 lbf ft) –

Screw, ground cable, on frame M6 7 Nm (5.2 lbf ft) –

Screw, handlebar stub M6 7 Nm (5.2 lbf ft) Loctite

243™

Screw, ignition coil M6 9 Nm (6.6 lbf ft) –

Screw, ignition lock M6 11 Nm (8.1 lbf ft) –

Screw, license plate holder on license

plate bracket

M6 7 Nm (5.2 lbf ft) –

Screw, magnetic holder on side stand M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, mirror holder M6 9 Nm (6.6 lbf ft) –

Screw, passenger seat M6 7 Nm (5.2 lbf ft) –

Screw, radiator air inlet, on frame M6 6 Nm (4.4 lbf ft) –

Screw, radiator holder M6 6 Nm (4.4 lbf ft) –

Screw, rear ABS sensor wheel

(RC 125)

M6 6 Nm (4.4 lbf ft) Loctite

204™

Screw, rear fender M6 7 Nm (5.2 lbf ft) –

Screw, retaining bracket, EFI control

unit

M6 6 Nm (4.4 lbf ft) –

Screw, shift lever linkage M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, side cover M6 7 Nm (5.2 lbf ft) –

Screw, side cover on front mask M6 6 Nm (4.4 lbf ft) –

Screw, voltage regulator M6 11 Nm (8.1 lbf ft) –

Screw, voltage regulator holder M6 11 Nm (8.1 lbf ft) –

Screw, wheel speed sensor holder

(RC 125)

M6 8 Nm (5.9 lbf ft) –

Screw, windshield M6 9 Nm (6.6 lbf ft) –

Fitting, engine mounting bracket M8 48 Nm (35.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, chain guard M8 11 Nm (8.1 lbf ft) –

Screw, engine bearer on frame M8 24 Nm (17.7 lbf ft) –

Screw, foot brake lever M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, front wheel spindle M8 26 Nm (19.2 lbf ft) –

Screw, fuel tank attachment, rear, on

frame

M8 16 Nm (11.8 lbf ft) –

Screw, horn M8 7 Nm (5.2 lbf ft) –

Screw, main silencer M8 24 Nm (17.7 lbf ft) –

Screw, passenger footrest bracket M8 26 Nm (19.2 lbf ft) Loctite

243™

Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, shift lever M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, top triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8x1 30 Nm (22.1 lbf ft) Loctite

204™

Banjo bolt, brake line M10 24 Nm (17.7 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –
