CRANKSHAFT
clearance
Allowable
limit
n
0.5
mm
0.0197 in.
f
\
0.2
rnrn
cs
I
0.008in.
0.4
rnm
0.016 in.
I
B
0071F006
46.1 to 46.3
rnm
1.81
5
to 1.823 in.
46.3
to
46.5
mm
1.823to1.831 in.
Cranks haft Alignment
1.
Support the crankshaft with V-blocks on the
surface plate and
set
a dial indicator with
its
tip on
the intermediate journal at right angle.
2.
Rotate the crankshaft on the V-blocks and get the
misalignment (half of the measurement).
3.
If
the
misalignment exceeds the allowable limit,
replace the crankshaft.
~-
C
0.02
mm
0.0008 in.
I
Misalignment
1.8
to 2.2
rnrn
radius
0.071 to0.087 in. radius
I
.8
to 2.2
mm
radius
0.071 to0.087 in. radius
Crankshaft Side Clearance
1.
Set a dial indicator with
its
tip on the end of the
crankshaft.
2.
Measure the side clearance by moving the
crankshaft to the front and rear.
3.
If
the measurement exceeds the allowable limit,
replace the thrust bearings.
4.
If
the same size bearing
is
useless because of the
crankshaft journal wear, replace
it
with an
oversize one referring
to
the table and figure.
I
I
Crankshaftside spec.
I
0.0059 to 0.0122 in.
I
Factory 0.15to0.31
mrn
0
Oversize dimensions
of
crankshaft journal
I
23.80 to 23.85
rnm
I
A
I
0.9134to0.9154in.
I
0.9213
to
0.9232 in.
23.40 to 23.45
mm
S-103
