Kubota U17-3a User Manual

116 W9232-8135-6
12/2015
Maintenance
Attaching and removing the engine compartment cover below the operator's seat
z Tilt the operator's seat (page 114).
z Unscrew the fastening screws (1) and remove the engine com-
partment cover (2).
z To attach the engine compartment cover, place it into position
and tighten the fastening screws.
Attaching and removing the cover below the operator's seat
z Tilt the operator's seat (page 114).
z Unscrew both wing screws (1) and remove the cover (2).
z To attach the cover, place it into position and tighten the wing
screws.
1
2
1
2

Kubota U17-3a Specifications

General

Bucket Capacity	0.04 m³
Make	Kubota
Model	U17-3a
Category	Excavators
Width	980 mm
Engine Model	Kubota D902
Engine Net Power	11.8 kW
Transport Width	980 mm
