OC60-E2, OC95-E2, WSM PTO SHAFT DIMENSIONS
12
A 35 mm dia. (1.38 in. dia.)
B 16.4 mm (0.65 in.)
C 72.2 mm (2.84 in.)
D 25.379 to 25.400 mm dia. (0.9992 to 1.0000 in. dia.)
G1 - 14 UNS
H 25 mm (0.98 in.)
0000009673E
A 35 mm dia. (1.38 in. dia.)
B 30.4 mm (1.20 in.)
C 75.5 mm (2.97 in.)
D 22.14 to 22.16 mm dia. (0.8717 to 0.8724 in. dia.)
E Taper 2 - 1 / 4 per foot
F 46.5 mm (1.83 in.)
G 5 / 16 - 24 UNF
H 18 mm (0.71 in.)
0000009674E
