Kubota WSM OC95-E2 - Page 50

OC60-E2, OC95-E2, WSM ENGINE
M-16
B [L TYPE]
(1) Glow Plug (5) Key Switch (9) Stop Solenoid Bl: Black
(2) Starter (6) Battery (12V) (10) Oil Pressure Switch Re: Red
(3) Dynamo (150 W) (7) Slow Blow Fuse (11) Warning Lamp (Option) Blu: Blue
(4) Regulator (8) Timer (12) Fuse (15A) Sb: Sky Blue
Gr: Green
Ye: Yellow
Bl / Wh: Black / White
Bl / Re: Black / Red
Re / Wh: Red / White
A The dot lines indicate option parts.
A The following modell is with stop solenoid.
OC60-E2-D1-QX-L1
OC95-E2-D1-QX-L1
0000009662E
