OC60-E2, OC95-E2, WSM ENGINE
S-9
FUEL SYSTEM
Item Factory Specification Allowable Limit
Injection Timing (Static) OC60-E2 0.26 to 0.30 rad
(15 to 17 )
before T.D.C.
OC95-E2 0.23 to 0.26 rad
(13 to 15 )
before T.D.C.
Fuel Tightness of Pump Element 14.7 MPa
150
2133 psi
Fuel Tightness of Delivery Valve 10 seconds or more
14.7 13.9 MPa
150 142
2133 2019 psi
5 seconds or more
14.7 13.9 MPa
150 142
2133 2019 psi
Fuel Injection Pressure 13.7 MPa
140
1987 psi
Fuel Tightness of Nozzle Valve Seat When the pressure is
12.7 MPa
(130 , 1849 psi)
the valve seat must be
fuel tightness
0000009182E
ELECTRICAL SYSTEM
Item Factory Specification Allowable Limit
Starter Commutator O.D.
(OC60-E2)
28.0 mm
1.1024 in.
27.0 mm
1.0630 in.
Commutator O.D.
(OC95-E2)
30.0 mm
1.1811 in.
29.0 mm
1.1417 in.
Mica Undercut
(OC60-E2)
0.45 to 0.75 mm
0.0177 to 0.0295 in.
0.2 mm
0.0079 in.
Mica Undercut
(OC95-E2)
0.50 to 0.80 mm
0.0197 to 0.0315 in.
0.2 mm
0.0079 in.
Brush Length
(OC60-E2)
10.0 mm
0.3937 in.
6.0 mm
0.2362 in.
Brush Length
(OC95-E2)
15.0 mm
0.5906 in.
10.0 mm
0.3937 in.
Alternator Changing Current
(Standard type)
4 to 6 A
at 3600
Changing Current
(L type)
14 A or more
at 3600
Glow Plug Glow Plug
Resistance
1.09 to 1.29
0000009184E
