7. - Instructions for transport
FC2860TLD-3160TLD-3560TLD
47
KN281CGB_L
Mower conditioner
7.2 Putting the machine into
transport position
From the working position:
- Activate single acting valve to raise the mowing
unit.
- Activate the double acting valve to pivot the
drawbar in transport position.
- Shut-off drawbar shift cylinder lock valve (1).
1
