11. - Maintenance and storage
FC2860TLD-3160TLD-3560TLD
99
KN281CGB_L
Mower conditioner
Side guard:
Left side:
Up to serial number C0402:
- Release and lift side guard using 18mm box
spanner supplied with the machine:
• The side guard automatically locks in raised
position.
or
From serial number C0403:
- Pull guard forwards (a) and lift it (b):
• The side guard automatically locks in raised
position.
- Intervene on the pitch angle adjustment rod for
easier access to the guard.
