GF8702
70
10. - Maintenance and storage
KN142BGB G
Gyrotedder
- Respect mounting instructions so that the
crop's pressure (a) closes the coils.
- Replace tine.
- Check attachment bolt, washer and nut.
Replace if necessary.
- Reassemble the unit.
- Check that the tine is properly embedded in
the tine arm.
- Tighten attachment screw:
• Torque: 18 daN.m (133 lbf.ft).
a
