KUHN GF8702 - Replacing a Synchronized Unfolding Cable

10. - Maintenance and storage
GF8702
71
KN142BGB G
Gyrotedder
10.4.4 Replacing a synchronized unfolding
cable
From the transport position:
If the cable is broken:
- Remove 2 bolts (1).
- Remove cable grip (2).
- Activate hydraulic valve that pressurizes the
transport/work position cylinder in the work
position direction until the outer rotors are just
above the ground.
- From the machine rear, pull lock (1) upwards by
hand. Secure it with a wedge (2).
1
1
2
1
2
