GF8702
74
10. - Maintenance and storage
KN142BGB G
Gyrotedder
- Remove wedge (2).
- Operate hydraulic valve that pressurizes the
transport/work position cylinders in the transport
position direction until the cylinders reach their
travel end.
- Fit cable (3) in cable clamp (2).
- Press cable clamp (2) against spring (4).
- Slightly tension cable manually making sure not to
unlock the lock.
- Fit the 2 bolts (1).
