Position conical center of dust seal (1) at the bottom.
Position their largest diameters at right angles to each
other.
Respect disk direction of rotation according to
fitting of knives.
On each knife, an arrow indicates the disk's
direction of rotation.
Make sure that the securing nut and bolt are in
good condition and if necessary, replace them.
Torque: 7.5 55 .
