Make a notch on the snap ring angle, close to its
opening with a chisel.
Step 2.
Place intermediate gearwheel in a vise.
Stop the snap ring from rotating by using locking pliers.
Step 3.
Page 47/95Printing date : 06-02-2014 GMD44_760001_xxxxxx
©Copyright KUHN S.A.
