Remove unit (1).
Remove seal (2).
Step 3.
Remove cover (1).
Remove shim rings (2).
Remove O
-
ring (3).
Note number and position of shim rings.
Page 58/95Printing date : 06-02-2014 GMD44_760001_xxxxxx
©Copyright KUHN S.A.
