Power harrow
30
HR6004DR
Putting into service
Parallelism of lower linkage arms
Adjust tractor lift rods so that lower linkage arms are at
equal height from ground.
Coupling the machine
- Remove the lower hitch pins.
- Position tractor lower links inside machine attachment
yokes.
- Position ball joints of tractor lower links in line with
holes of machine lower yokes.
- Position bushes (1) inside frame coupling yokes.
- Insert lower hitch pins and secure them with lynch
pins.
2 bushes diameter 37 mm (1.45’’) are supplied
with the machine. Part no. K2501780
