Putting into service
Power harrow
HR6004DR
31
.
- Attach top link with hitch pin.
• Use tractor and machine attachment holes to adjust
the top link position.
- Insert hitch pin anti-rotation arm (1) in the machine
mounting yoke and secure with lock pin.
Hydraulic connections
Connect the 2 hydraulic hoses of the transport/work
cylinders to a double acting valve.
Electrical connections
Connect 7-pin plug to the tractor.
To obtain optimum PTO shaft angles and
tractor lift capacity, the top link must be
parallel to the lower links or slightly pointing
downwards towards the tractor.
