KUHN SpeedRake SR112 - Machine Specifications; Component Glossary

SpeedRake
18
SR108 SR110 SR112
Machine specifications
$Machine specifications
1. Description and glossary
1 Clevis 8 Right finger wheel 15 Transport wheel
2 Jack 9 Left finger wheel 16 Right and left twin wheel mount
3 Main frame 10 Primary pivot assembly 17 Finger wheel hub
4 Stop pad 11 Lift cylinders 18 Mount retainer
5 Turnbuckle 12 Link bar 19 Spacer tube (SR110/SR112)
6 Telescopic arm 13 Primary pivot cap 20 Secondary pivot
7 Rake arm 14 Primary pivot pin 21 Single wheel mount
8
21
2
9
1
20
19
18
17
16
15
14
13
3
5
4
6
7
10
11
12
