KUHN SpeedRake SR112 - Optional Equipment; Center Kicker Wheel

SpeedRake
32
SR108 SR110 SR112
Optional equipment
$Optional equipment
1. Center kicker wheel
The center kicker wheel (1) is used to fluff the center part
of the windrow. It can be used when raking 3 windrows
together or after mowers or tedders have been used.

Center kicker wheel parts
1
1: Rake wheel
2: Kicker wheel mount
3: Hydraulic cylinder
4: Hydraulic lock-out valve
5: Eye bolt
6 Adjustment nut
7Spring
6
1
3
5
2
4
7
