KUHN SpeedRake SR112 - Hydraulic Hose Length Adjustment

Instructions for work
SpeedRake
SR108 SR110 SR112
31
5. Adjusting hydraulic hose length
- Loosen clamp nut (1) until hydraulic hoses (2) move
freely.
- Slide hoses in or out of the tongue tube until they are
the desired length.
- Retighten clamp nut (1) to secure hoses.
1
2
