14 Service Manual EKI
For internal use only
4.5 Power characteristics
The parameters for the power characteristics are stored in an EEPROM for each cooking zone.
DC = Duty cycle
4.6 Key-lock function
The appliance can be locked to prevent unauthorised use with the key-lock button.
On hobs manufactured up to June 1999 this children’s safety feature is switched on and off again with
the key-lock button.
On hobs manufactured after July 1999 the children’s safety feature is only switched on with the key-lock
button. It is switched off by pressing the buttons "On" and "Key-lock" at the same time and the "Power"
button within 5 seconds (these buttons are easy to find as the LEDs flash).
4.7 Saucepan sensors
Every induction cooking zone is equipped with saucepan sensors. They prevent activation as long as no
saucepan has been placed on the zone or if unsuitable saucepans are used. If the saucepan is removed
during use, the power is cut off.
As long as the cooking zone is switched on, any missing or unsuitable saucepan is displayed on the
corresponding actuator display with the symbol "Saucepan missing" (see Annex C).
The saucepan sensors operate for 10 minutes. If no suitable saucepan is placed on the cooking zone
during this time, the zone is switched off. The display changes from the symbol "Saucepan missing" to 0.
Cooking
level
Nom. power Cooking
zone 1
(Ø 180mm)
Cooking
zone 2
(Ø 145mm)
Cooking
zone 3
(Ø 210mm)
Cooking
zone 4
(Ø 145mm)
Code %
%
DC
Watt
%
DC
Watt
%
DC
Watt
%
DC
Watt
1 2.5 13.7 55 13.7 35 13.7 45 13.7 35
2 5.0 27.8 110 27.8 70 27.8 90 27.8 70
3 7.5 41.6 165 41.6 105 41.6 135 41.6 105
4 12.5 69.4 275 69.4 175 69.4 225 69.4 175
5 18.0 100.0 396 100.0 252 100.0 324 100.0 252
6 24.0 100.0 528 100.0 336 100.0 432 100.0 336
7 45.0 100.0 990 100.0 630 100.0 810 100.0 630
8 60.0 100.0 1320 100.0 840 100.0 1080 100.0 840
9 100.0 100.0 2200 100.0 1400 100.0 1800 100.0 1400
P 136.4 100.0 3000 ––––––
